TWO MICS IN ONE
The LA-220’s onboard analog sound-shaping eliminates the need for mic swaps and downtime, which means you can focus on the main thing --- making music. Capture vocals with presence and punch or an electric guitar without any annoying high-end sizzle.
CUSTOM CAPSULE
The LA-220 utilizes the same upgraded capsule as its larger tube sibling, the LA-320. Unlike traditional capsule designs, our hand-tuned 32mm transducer naturally imparts gentle compression and balance to any sound source, making it ideal for use in an array of string, percussion, and vocal applications.
WHAT'S INSIDE MATTERS
Hand-soldered with high resolution, low distortion polypropylene capacitors and resistors, a US-made ultra-low noise JFET, and a vintage-inspired output transformer.
IN THE BOX
LA-220 / SPIDER SHOCK MOUNT / MICROPHONE BAG
SPECIFICATIONS
& DIAGRAMS
TYPE
TRANSFORMER-BALANCED FET CONDENSER
CAPSULE
32MM CENTER-TERMINATED PRESSURE GRADIENT
POLAR PATTERNS
CARDIOID
FREQ. RESPONSE
20HZ - 20kHz
HIGH PASS
FLAT / 120Hz
LOW PASS
FLAT / 12kHz
DYNAMIC RANGE
120DB MINIMUM
MAX. SPL
0.5% THD @1000HZ: 130DB
IMPEDANCE
<200 OHMS
SELF-NOISE LEVEL
< 15DB-A
SENSITIVITY
16MV/PA -40DB (ODB=1V/PA 1KHZ)
CONNECTOR
3-PIN XLR
POWER
REQUIRES 48V PHANTOM POWER
BOX DIMENSIONS
5" x 10" x 10"
IN-BOX WEIGHT
3.9lbs
MIC W/ MOUNT WEIGHT
1lb 9oz
HIGH & LOW CUT FILTERS
CONTENT FROM OUR
EXTENDED FAMILY
#LAUTENAUDIO
DESIGNED & TESTED
IN SILICON VALLEY, CA
EACH LA-220 IS LOVINGLY DESIGNED & CRAFTED TO LAST A LIFETIME BY THE LAUTEN AUDIO FAMILY
