THE HEIR OF A JUGGERNAUT
The LA-320 is a twin-tone tube microphone that allows you to choose between the warmth and body of a vintage tube microphone and the clarity and presence of a modern tube microphone at the flip of a switch. Classic tube microphones were made for a signal chain that you don’t have, so we designed the LA-320 to sound great without it. Centered around a custom-made Lauten Audio capsule and hand-soldered tube circuit path, our unique microphone design gives you the musical color and gentle compression associated with classic signal chains but straight into your audio interface.

TWO TUBE MICS IN ONE
The LA-320’s onboard sound-shaping eliminates the need for mic swaps and wasted time. Choose between the warmth of a classic tube microphone and the clarity of a modern tube microphone at the flip of a switch. Capture the wood of a worn-out acoustic guitar and the air of a pop vocal with the same microphone at the flip of a switch.

CUSTOM-CRAFTED CAPSULE
Unlike classic capsule designs, our newly improved, hand-tuned 32mm transducer naturally imparts gentle compression and balance to any sound source, making it ideal for use on traditionally troublesome applications. This means getting a great recording in the real world is faster and easier.
INSIDE STORY
The LA-320 is hand-soldered with high-resolution, low-distortion polypropylene capacitors and resistors, a dual triode vacuum tube, and a vintage-inspired output transformer. The resulting sound is crisp, clear, and full without the high noise floor and delicacy of vintage microphones.

IN THE BOX
LA-320 / SPIDER SHOCK MOUNT / POWER SUPPLY / 5-PIN CABLE

LA-320

SPIDER SHOCK MOUNT

POWER SUPPLY

5-PIN CABLE
SPECIFICATIONS
& DIAGRAMS
TYPE
TRANSFORMER BALANCED TUBE CONDENSER
TUBE
ECC83
CAPSULE
32MM CENTER TERMINATED PRESSURE GRADIENT
POLAR PATTERNS
CARDIOID
FREQ. RESPONSE
20HZ - 20KHZ
HIGH PASS
FLAT / 120Hz
LOW PASS
FLAT / 12kHz
DYNAMIC RANGE
120DB MINIMUM
MAX. SPL
0.5% THD @1000HZ: 130DB
IMPEDANCE
<200 OHMS
SELF-NOISE LEVEL
< 17DB-A
SENSITIVITY
14MV/PA (@1KHZ 74DB SPL)
CONNECTOR
5-PIN XLR (PSU TO MIC) + 3-PIN XLR (PSU TO PREAMP)
POWER
REQUIRES INCLUDED PSU (SWITCHABLE 100V TO 240V)
BOX DIMENSIONS
5” x 12” x 15”
BOX WEIGHT
8.2lbs
MIC W/SHOCK WEIGHT
1lb 11oz


HIGH & LOW CUT FILTERS
